Verfahrwege |
X-Achse (mm) |
360 | 440 | 580 | 660 | 800 | 3.200 | 1.500 |
Y-Achse (mm) |
520 | 610 | 950 | 1.020 | 950 | 2.250 | 2.040 |
Z-Achse (mm) |
610 | 520 | 500 | 750 | 1.200 | 1.000 |
A-Achse (°) |
+30 / -120 | +30 / -110 | +/- 120 | | +/- 110 |
B-Achse (°) |
| | | | | +/- 105 | |
C-Achse (°) |
360 | +/- 220 | 360 |
Arbeitsbereich |
Tisch - Aufspannfläche L x B (mm) |
Ø 250 | Ø 320 | Ø 398 | Ø 600 | Ø 800 | 3.320 x 2.100 | 1.000 x 1.000 |
Tischbelastung (gleichmäßig) (kg) |
100 | 200 | 250 | 500 | 1.200 | 8.500 | 2.500 |
Spindelnase -Tisch (mm) |
65 - 675 | 90 - 610 | 90 - 590 | 160 - 660 | 150 - 900 | 100 - 1.300 | 0 - 810 |
T-Nuten (DIN 650) |
6 x 12mm - 60° | 4 x 12mm - 90° | 6 x 14mm - 60° | 5 x 14mm x 100mm | 7 x 14mm x 100mm | 10 x 22mm x 200mm | 9 x 18mm x 100mm |
Hauptspindel |
Spindelkonus |
SK40 - BigPlus / BBT40 | HSK63-A / SK40 - BigPlus / BBT40 | HSK100-A | HSK63-A |
Antriebsart |
In-Line | Motorspindel |
Spindelleistung S1/S6 (kW) |
10 / 14 | 25 / 30 | 42 / 55 |
Spindeldrehmoment S1/S6 (Nm) |
63,7 / 89,4 | 120 / 144 | 66,8 / 87,5 |
Spindeldrehzahl max. (U/min) |
15.000 | 12.000 | 24.000 |
Vorschub |
Eilgang X/Y/Z-Achse (m/min) |
36 / 36 / 24 | 36 | 48 | 16 | 20 / 16 / 16 |
Arbeitsvorschub X/Y/Z-Achse (m/min) |
12 | 20 | 24 | 12 |
Eilgang A/B/C-Achse (1/min) |
25 / - / 25 | 16,7 / - / 22,2 | 25 / - / 25 | 25 / - / 33 | 50 / - / 100 | - / 100 / 100 | 180 / - / 50 |
Arbeitsvorschub A/B/C-Achse (1/min) |
25 / - / 25 | 16,7 / - / 22,2 | 25 / - / 25 | 25 / - / 33 | 50 / - / 100 | - / 100 / 100 | 180 / - / 50 |
Werkzeugwechsler |
Bauart Werkzeugwechsler |
Doppelgreifer | Pick-Up | Doppelgreifer |
Magazinplätze |
24 | 30 | 40 | 32 | 40 |
Werkzeugdurchmesser max. (mm) |
| 75 | 90 | 125 | 75 |
Bei freien Nebenplätzen (mm) |
120 | 150 | 125 | 180 | 100 |
Werkzeuglänge max. (mm) |
| 280 | 300 | 400 |
Werkzeuggewicht max. (kg) |
7 | 15 | 7 |
Weitere Daten |
Erforderliche Stellfläche (mm) |
2.660 x 2.160 x 3.300 | 2.210 x 3.035 x 3.225 | 3.000 x 2.560 x 3.170 | 3.255 x 3.855 x 3.520 | 4.120 x 4.830 x 4.000 | 8.700 x 5.800 x 6.000 | 4.590 x 4.625 x 4865 |
Maschinengewicht (kg) |
6.700 | 5.720 | 9.500 | 14.000 | 18.000 | 44.000 | 28.000 |
Elektrischer Anschluss (kVA / A) |
40 | 75 | 60 / 160 | 80 / 160 |
Druckluftanschluss (bar) |
6 | 10 |
